Ground support equipment TLD ACU-804-DUS

DESIGN SPECIFICATIONS

Cooling Capacity Nominal Tons Refrigeration 65

Air Flow lb/min (kg/min) to 375 (170)

Supplied Air Temperature (@100°F & 50% RH) °F (°C) 35-50 (2-10)

Compressor Manufacturer Frick

Compressor Model XJS-120S

Compressor Type Rotary Screw

Capacity Control Automatic, Pressure Controlled

Heating Capacity btu/hr (kW) 350,000 (103)

Heating Ambient °F (°C) Below 0 (Below 0)

Heating Air Temperature °F (°C) 90-110 (38-52)

DIMENSIONS (Approximate)

Mounting Trailer - Skid

Length (cm) 516 - 355

Width (cm) 218 - 218

Height (cm) 236 - 198

Weight (kg) 4410 - 4180
